Specifications
| Brand Name | STMY |
| Product Name | Pit Design Cantilever Parking Lift |
| Model No. | QDMY-2-5B, QDMY-4-10, QDMY-6-15 |
| Mode of Operations | Manual buttons/Keys |
| Mode of drive | Hydraulic |
| Car Capacity | 2500kg |
| Car Size (L×W×H) | ≤5000x1850x1650(mm) ≤5000x1850x1950(mm) |
| Lifting speed | 4-6m/min |
| Lifting Height | 1600-2000mm Customized |
| Safeguard device | Whole protection and anti-falling lock device |
| Lifting Speed | 4-6m/min |
| Stop at any height | Yes, can be set |
| Work Noise | < 60dB ( A ) |
| Electricity | 220/380V/415V
(Customized for different country) |
| Motor Power | 2.2KW |
| Maximum Working Pressure | 16 MPa |
| HS Code | 84289020 |
| Surface Treatment | High-grade anti-corrosion paint |
| Color | Red, Blue, Grey, Yellow etc.
(customized according to user demand ) |
| Certification | ISO9001 and CE |
Working Principle
The spaces of top, middle and bottom are united and lifted together.
Usually, the bottom and middle level spaces are underground in the
pit.
The top level space is in the same line with the ground.
The top level car can park in and out directly.
When the system is lifed up, the drive can pick or park car easily.
Descriptions
1. Simplicity of operation, economic and practical design, one
parking unit for 2, 4 or 6 cars
2. Pit type stacker,can be used in household or office building
parking lot.
3. Sharing post design, space saving, economic and steadier.
4. No steel structure above ground, simple and graceful
5. The upper and lower space are fixed together, normally, the
system lower to the pit, you
can park car on upper space directly or rise the system to park the car on lower space.
6. Multiple safety protection device
7. Optional hydraulic oil cylinder or motor & chain driven mode
8. Wave plate or diamond plate are optional ,you can choose hot galvanizing,electroplating or
powder spray
9. Mold machining through the whole process so that the parts are universal and interchangeable
Pass 120% capacity dynamic load text and 150% static load test.
11.Italian oil seal to make sure no oil leakage,inner
anti-explosion valve in case of platform drop
12. Optional ultrared rays alarm device, in case of unguarded
entrance
Adapted places
Widely using in residential parking lot, hotels, schools, office
buildings, apartment, etc…
Online Video link
https://youtu.be/-DbtNlK-5C0
Pictures
Structure and Dimensions:
QDMY-2-5B
QDMY-4-10
QDMY-6-15
FAQ
1. What trade term you can accept?
---FOB, CFR, CIF, EXW, FCA. (If you want check the shipping cost,
tell us your port name).
2. What payment term can you accept?
---30%TT in advance, and 70%TT before shipping.
3. How about the loading information and HS Code?
---The HS code is 84289020
---15 car spaces can be loaded into 1x40'GP container.
4. How about the lead time?
---30-45 days (According to order quantity).
5. Can you provide OEM service?
---Yes, we can provide OEM service according to the requirement of
the client.
6. Can you make design for our land?
--Yes, send me your land layout, our engineer can make design and
provide the best parking solution to you and your clients.
7. Do you provide training services?
---Yes, we provide free trainning services in our factory, to teach
your engineer about how to install and rountine mantenace
knowledge;
8. How about the installation?
---This model of product is relatively simple structure, usually we
send installation manual to the client, and they can install it
themselves.
---We can also send 1-2 engineers to your country to guide the
installation, commissioning, training your staff.
9. What is warranty term?
---12 months for electrical parts, 5 years for mechanical
structure.
10. What are the certificates?
---ISO9001 & CE.
11. The car size and car height can be customized?
---The platform size, lifting height can be customized according to
customer's request.
12. Does model QDMY-2-5B can share columns?
---Yes, it can share columns for multi-units.
Note: For a full complete set of drawings, send email to: totti.yu@qdmy-parking.com
